Indoor Wall Mount Panel Antenna | #1 Airtel Jio & Vodafone Network

About this item
- [Antenna Type] This directional cellular antenna is designed for indoor used. Directional Panel Antenna will provide much stable signal strength and farther distance.
- [Antenna Connector ] The Indoor directional panel antenna features a N-Female Connector that facilitates the transfer of high-frequency information, easy to install.
- [Antenna Frequency Range] The Inside Panel Antenna is a 50 Ohm, indoor wall-mount antenna used to 2G, 3G , 4G, 5G signals(698 - 40000 MHz). Most powerful wide-band coverage features up to +9.5 dB gain. It helps avoid dropped calls and improve data speeds in home and office, enjoy a happier life and more productive workspace. Best for priority area coverage and corridors.
- Antenna Installation] The cell phone antenna signal booster with N-Female connector, come with wall mount bracket, no technical experience required, easy to install. After affixing the mounting plate to the wall, mount the antenna onto the mounting plate by sliding it into the slots and securing it with the provided fasteners.
- [Warm Tips] Please note it’s a indoor antenna, as a part of signal booster kit, it does not generate any signals. Clients should use it with a signal booster.

Report an issue with this product or seller

Note: Products with electrical plugs are designed for use in the . Outlets and voltage differ internationally and this product may require an adapter or converter for use in your destination. Please check compatibility before purchasing.

Top Selling Wireless Cellular GSM 2g 3G 4G Mobile Network Signal Repeater Cell Phone Signal Booster

WT-CDW04 850/1800/2100MHz

A mobile phone signal repeater provides the ultimate solution in any area where cellular communications can not work well due to leak of signals. The repeater device features easy installation & operation, build-in indoor antenna and no interference. It could also improve indoor electromagnetism environments, protract cellular battery life and reduce radiation of cellphones. A mobile phone repeater is ideal for house, home, office use.

Introduction To Mobile Phone Signal Repeater

1. Enhance Mobile Phone Signal Strength

2. Improve Communication Quality

3. Reduce Cellphone Radiation

4. Protract Cellular Battery Life

5. Economic Building Cost

6. Easy Operation

7. Easy Installation

8. Build-in Power Supply

The repeater makes the signal stronger in places with poor signal coverage such as:

1) Underground areas: basements, parking lots, tunnels;

2) Other places where cellular signal is shielded by metal or concrete walls: offices, supermarkets, cinemas, hotels;

3) Places distant from the BTS like private houses.

How does the Booster/Repeater Works?

Repeaters are designed to fulfill the idea of one and main principle: to fill the areas with the weak or bad signal and to amplify these low signals in order to provide you with the communication suitable for you.

Tri-band 850/1800/2100MHz description:

Frequency range	Uplink: 824-849/1710-1785/1920-1980MHz Downlink: 869-894/1805-1880/2110-2170MHz
Gain ( dB)	Uplink: 60±3dBi Downlink: 65±3dBi
Export power (Po)	20dBm±3dBm
Power supply	AC110V-240V 45~55Hz
Size	23218222mm
coverage area	1000 square meters
Pass band ripple	≤3dB
I/O impedance	50Ω/N connector
Noise figure	≤4dB
Transmission Delay	≤0.5μ s
Ambient temperature	-10ºC~60ºC
Reliability	To the GB6993-86 standard
Electromagnetic compatibility	To the ETS300 694-4 standard
Function	a) Power supply LED denote b) Export power LED denote
